ADJ Vizi Beam RX2

Elevate your lighting performance with the ADJ Lighting Vizi Beam RX2, a compact and quick moving head beam fixture designed for the modern lighting designer.

Featuring a vigorous 100W Osram Sirius HRI discharge lamp with a 6,000-hour lifespan, this potent fixture delivers stunning visuals with a precise 2-degree beam angle, as well as, high speed 3-phase pan/tilt motors for maximum performance.



£779.00

Description

Unlock a wealth of features including on-board wireless DMX, two prism wheels (16-facet circular & 4-facet linear), a frost effect, motorised focus (with 16-bit fine focus), along with a 14-color dichroic wheel that includes CTO (3200K), CTB (9000k) & UV filters) and 15 static GOBOs + open (3 GOBOs are beam reducers).

Designed for convenience, it features outdoor-rated In/Out locking connections for power daisy-chaining, 5-pin In/Out DMX sockets and a colour LCD display with 4-button function menu. The Vizi Beam RX2 is a versatile and reliable lighting solution for any high-octane event.

Specifications

Light Source

  • OSRAM Sirius HRI 100W Discharge Lamp (6,000 hr.)
  • Colour temperature: 9000K (+/- 300K)

Features

  • On-Board Wireless DMX
  • Motorized Focus + 16-Bit Fine Focus
  • 2-Degree beam angle
  • Frost Filter (to create wash effect)
  • High Quality Glass Lens
  • 2 Rotating Prisms
  • 0-100% Smooth Dimming
  • Various Strobe Speeds
  • OTA, wireless, firmware updates
  • Fan cooled

Colour Wheel

  • 14 Dichroic Colours + white (Includes CTO (3200K), CTB (9000K) & UV)
  • Indexable Colour Wheel (for Split Colours)

Gobo Wheel

  • 15 static GOBOs + open (3 GOBOs are beam reducers)
  • GOBO Shake Effect

Prism Wheel

  • 2 Rotating prisms
  • 16-Facet circular and 4 facet linear prisms

Control

  • Protocols: DMX512 & RDM
  • Control Mode: DMX512 & Manual (On-board Controls)
  • Aria X2 Wireless Management / DMX System
  • 2 DMX Channel Modes: 12/16 Channels
  • Colour LCD display with 4-button function menu
  • 0-100% smooth dimming
  • Various strobe speeds

Pan/Tilt

  • Pan: 540 Degrees (plus 16-bit fine pan)
  • Tilt: 270 degrees (plus 16-bit fine tilt)
  • 3-Phase, High Speed, Pan/Tilt Motors

Connections

  • DMX Connections: 5-pin DMX In/Out (Data link max: 32 fixtures)
  • Power Connections: Outdoor locking In/Out connections to daisy chain power

Electrical

  • Multi-voltage Operation: 100-240V, 50/60Hz
  • Max power consumption: 157W

Dimensions & Weight

  • Dimension: 230 x 304 x 416mm
  • Weight: 7.5 kg.

Approvals / Ratings

  • CE
  • cETLus (Pending)

What’s Included

  • 2x Omega Brackets (107 Type)
  • 1x 2M, Outdoor Locking 14AWG Power Cord
