ADJ Vizi Pix Z19 Wash



Vizi Pix Z19 is a high-performance moving head wash fixture engineered to deliver vibrant colour effects and captivating visuals for professional stages and live events.

Equipped with nineteen 30W RGBL LEDs, the fixture offers advanced virtual CMY colour mixing, a wide motorised zoom range and smooth electronic dimming, making it ideal for crafting everything from precise beams to expansive washes.

Its dynamic design is enhanced by 30 RGB background LEDs and a 40-light RGB LED ring. Both foreground and background LEDs are fully pixel-mappable for complex patterns and dazzling effects. Built-in pixel effect programs and colour macros further expand its creative possibilities.



£926.50

Description

Vizi Pix Z19 is a high-performance moving head wash fixture engineered to deliver vibrant colour effects and captivating visuals for professional stages and live events.

Equipped with nineteen 30W RGBL LEDs, the fixture offers advanced virtual CMY colour mixing, a wide motorised zoom range, and smooth electronic dimming, making it ideal for crafting everything from precise beams to expansive washes. Its dynamic design is enhanced by 30 RGB background LEDs and a 40-light RGB LED ring. Both foreground and background LEDs are fully pixel-mappable for complex patterns and dazzling effects. Built-in pixel effect programs and colour macros further expand its creative possibilities.

Control options include DMX, Art-Net, sACN, RDM, and the Aria X2 wireless system for seamless integration and over-the-air updates. Adjustable dim curves, selectable LED refresh rates, and a white colour temperature range from 2700K to 10,000K ensure flexibility across diverse environments, from live performances to broadcast studios.

With robust pan/tilt locks, durable Seetronic power and data connections, and a lightweight, low-maintenance build, the Vizi Pix Z19 is the ultimate tool for creating striking, professional-grade lighting displays with unmatched precision and versatility.

Primary Light Source

  • 19 x 30W quad-colour LEDs (RGBL)
  • Adjustable beam angle: 7°- 42°
  • Adjustable field angle: 9°- 60°
  • 93,750 Lux @ 2m
  • CRI: 86
  • Full pixel mapping capabilities

Background Light Source

  • 30 x 0.5W tri-colour SMD 5050 LEDs (RGB)
  • Full pixel mapping capabilities

Ring Light Source

  • 40 x 0.5W tri-colour SMD 5050 LEDs (RGB)
  • 3 pixel zone mapping capabilities

Features

  • Power consumption: 690W
  • Power supply: 100~240V, 50/60Hz
  • Control protocols: DMX, Art-net and sACN
  • DMX channels: 32/43/58/58/123/133 or 203 selectable
  • Virtual CMY DMX control modes
  • Virtual foreground and background colour wheel control
  • Built-in colour macros
  • Colour temperature presets
  • Wireless control (Aria X2 Management System)
  • Manual control and primary/secondary modes plus built-in programs
  • Pan/tilt transit lock and auto correction
  • 16-Bit pan/tilt positioning
  • Pan: 540° or 630° selectable, Tilt: 265°0
  • 100% dimming
  • 6 dimming modes: Standard, stage, TV, architectural, theatre and stage 2
  • Variable strobe
  • Quick release omega clamps included
  • RDM (Remote Device Management)
  • 6 button menu with LCD display
  • PowerTwist TR1 input/output
  • 5-Pin XLR input/output
  • RJ45 input/output
  • Fan cooled

Dimensions

  • Dimensions (HxWxD): 408 x 310 x 230mm
  • Weight: 10.1kg

Downloads

Additional information

Weight 10.1 kg
Dimensions 23 × 31 × 40.8 cm
