Description
The M-12 features a dual output nozzle and dual pump system that can be controlled either independently or simultaneously, allowing a wider range of volume adjustment and output flexibility. Automatic sequential pump operation can produce endless volumes of fog in continuous mode, making the M-12 the highest output fog machine ever created by Antari.
Versatile control options include a built-in electronic timer, DMX with RDM, stand-alone operation and an optional wireless remote control. The M-12 is flexible enough for small theatres and powerful enough for the largest arenas.
Specifications
Electrical Specifications and Connections
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 2000 W
- Power Connector In: powerCON TRUE1
- DMX Connector: XLR 3P In/Out, XLR 5P In/Out
- DMX Connector In: XLR 3P, XLR 5P
- DMX Connector Out: XLR 3P, XLR 5P
- Heater: 2000 W
- Warm-up Time: 13 min
Mechanical Specifications
- Output Direction: Forward
- Housing: Metal
- Colour: Black
- Fluid Consumptionl: 400 ml/min (13.526 oz/min)
- Length (mm): 645 mm (25.394″)
- Height (mm): 283 mm (11.142″)
- Width (mm): 280 mm (11.024″)
- Weight: 27.2 kg (59.966 lb)
- IP Rating: IP20 (indoor use only)
Control and Programming
- Control Mode: DMX, Manual, Timer
- DMX Channels: 1, 3
Thermal Specifications
Included Items
- Included Cables: Power Pro True Cable
