Description

Features

• Peakx Plus™ Limiters provide the ultimate in system performance and protection by allowing full control over threshold, attack, and release
• Enhanced Subharmonic Synth section provides user control over frequency, gain and filter type for system-specific tuning
• 3 User-defined fan mode controls – normal, early and fullspeed – for matching fan performance to a specific application
• New system monitoring provides software visibility of AC line voltage and power supply temperature
• Integrated cast-aluminum handles for easy handling and enhanced durability
• Locking power cord clip provides a secure connection between the amplifier and power cord
• Updated HiQnet System Architect™ control software
• Increased number of presets to a total of 50; 49 of which are user definable

Specifications

• Channels: 2
• Sensitivity: 1.4V
• Rated Power Output (per channel): 1000W 2Ω, 800W 4Ω, 475W 8Ω
• Signal to Noise Ratio (below rated 1 kHz power at 8 ohms): 100 dB (A-weighted)
• THD: < 0.5%
• Frequency Response (at 1W, 20 Hz – 20 kHz): + 0 dB, -1 dB
• Crosstalk (below rated power) 20 Hz to 1 kHz: >70 dB

Physical & Dimensions

• Height: 3.5″
• Width: 19″
• Depth: 12.25″
• Weight: 8.4kg
