Performance |
|
Frequency Range (-10 dB) | 40 Hz – 125 Hz |
Maximum Peak SPL at 1 m | 131 dB |
Electronics and Connectors |
|
Nominal Amplifier Power (continuous) | 600 W |
Nominal Amplifier Power (peak) | 1200 W |
Input Type | Balanced |
Input Impeadance | 20 kohms |
Input Sensitivity | 1.95 V (+8 dBu) |
Audio Signal Input Connector | 2 x Female XLR |
Audio Signal Loop Thru Connector | 2 x Male XLR |
Control | DAScontrol™ |
AC Output Connector | powerCON NAC3MPB |
Current Draw 230 V / 115 V | 1.4 A/2.8 A |
Enclosure |
|
Enclosure Construction | Birch Plywood |
Enclosure Geometry | Rectangular |
Rigging | Captive Rigging System |
Finish | ISO-flex Paint |
Color | Black |
Dimensions ( H x W x D ) | 480 x 485 x 765 mm 18,9 x 19,1 x 30,3 in |
Net Weight | 37,0 kg ( 81,5 lb ) |
Components |
|
LF Driver | 15FW4 |
Shipping |
|
Carton Dimensions ( H x W x D ) | 530 x 550 x 860 mm 20,9 x 21,7 x 33,9 in |
Shipping Weight | 40,5 kg ( 89,1 lb ) |
- Active front-loaded subwoofer system
- 1 x 15″ DAS 15FW4 loudspeaker
- High-efficiency Class D amplifier with SMPS
- Dual voltage mains for use anywhere in the world
- Easy system configuration thanks to DAScontrolTM
- High-end 24-bit DSP with LCD screen
- EVENT-26A compatible rigging hardware
Applications
- House of worship
- Theatres, auditoria and performing arts centers
- Live music clubs
- Corporate A/V
- Live sound touring/Rental services
Price From £30.00 +VAT Per Day
