Name: IMST Distribution Box 32A 240V In 9030331
SKU: CONN376
Price: 295.00 GBP
Availability: InStock

IMST Distribution Box 32A 240V In, 4x16A + 1x32A Out (9030656)

IMST Distribution Box 32A 240V In-4x16A + 1x32A Out (9030656)

These PCE IMST distribution boxes are handy, robust, lightweight and made of shock-resistant polyamide.

They feature a high-grade steel folding carry handle, have stackable design and are IP44 rated.

£295.00

Description

These PCE IMST distribution boxes are handy, robust, lightweight and made of shock-resistant polyamide.

Features

Handy, robust and lightweight distribution box made of shock-resistant polyamide

High-grade steel folding carry handle

Number of modules: 6

IP44 rated

Stackable design

Made in the EU

Specifications

Input: 32A 220-250V~50/60Hz 3-Pin 2P+E IP44 inlet
Outputs: 1 x 32A 220-250V~50/60Hz 2P+E IP44 socket, 4 x 16A 220-250V~50/60Hz 2P+E IP44 sockets each protected by 16A 1P MCB C Curve
Type A 32A 30mA 2P RCBO protecting all outputs
Dimensions (H x W x D): 196 x 245 x 300mm
Weight: 2.7kg
