Description

The Club XS+ models incorporate all of the great features of the standard Club range, now with the inclusion of a DSP On/Off foot switch socket and an aesthetic overhaul, redesigned control knobs and finished in Studiomaster digital black.

Compact, portable mixing consoles featuring 5 to 16 inputs, Bluetooth connectivity, on-board DSP effects and USB/SD card playback and recording functions. 3 band EQ, 2 auxiliaries, balanced mic/line connectors, compressor control, and a useful mute switch on all Mic and line input channels, 2 band EQ with 2 auxiliaries for both stereo channels. There are also balanced XLR connectors for the main outputs, jacks for auxiliaries and control room, and phono connectors for analogue record and playback.

Features

• 16 inputs (12 mic channels, 2 stereo channels)
• 3 auxiliary busses for monitoring and internal/external effects processing
• Professional balanced outputs
• High-quality microphone preamps with enhanced compression, gain controls, and 3-band EQ on all mic channels
• 60mm smooth faders for precise control
• PFL and mute control on every channel
• 16 built-in DSP effects (reverb, delay, and stereo effects)
• Footswitch socket for easy DSP on/off control
• Internal power supply for reliable performance
• Bluetooth playback functionality
• USB/SD card media module for playback and recording
• Compressor and 100Hz high-pass filter on all mic channels
• 3-band EQ on mic channels for superior tone shaping
• 2-band EQ on stereo channels for adding warmth to instruments
• AUX & DSP outputs for monitor mixes and external effects
• Stereo return with intuitive level control
• RCA/Phono playback and recording support
• Headphone and control room outputs for full monitoring
• +48V phantom power on mic channels for condenser microphones

Downloads

User Guide
