Description

The Club XS+ models incorporate all of the great features of the standard Club range, now with the inclusion of a DSP On/Off foot switch socket and an aesthetic overhaul, redesigned control knobs and finished in Studiomaster digital black.

Compact, portable mixing consoles featuring 5 to 16 inputs, Bluetooth connectivity, on-board DSP effects and USB/SD card playback and recording functions. 3 band EQ, 2 auxiliaries, balanced mic/line connectors, compressor control, and a useful mute switch on all Mic and line input channels, 2 band EQ with 2 auxiliaries for both stereo channels. There are also balanced XLR connectors for the main outputs, jacks for auxiliaries and control room, and phono connectors for analogue record and playback.

Features

• 8 inputs (4 mic channels, 2 stereo channels)
• 16 DSP effects (reverb, delay, and stereo effects)
• Bluetooth playback capability
• USB/SD card media module for playback and recording
• Compressor and 100Hz high-pass filter on all mic channels
• Mute button on each channel
• 3-band EQ on mic channels for detailed tone adjustments
• 2-band EQ on stereo channels for adding warmth to instruments
• AUX & DSP outputs for monitor mixes and external effects
• Stereo return with intuitive level control
• RCA/Phono playback and recording support
• Headphones and control room outputs for full monitoring
• +48V phantom power on mic channels for condenser microphones

Dimensions & Weight

• Width: 305 mm
• Depth: 365 mm
• Height: 80 mm
• Weight: 4.5 kg

Downloads

User Guide

Additional information
