Ventis 110

2-way Passive speaker – 10″ + 1″ – 300Wrms

Ventis 110 is part of the Ventis range which are ideal for portable performance or fixed installation. This passive speaker features an 10″ woofer and a 1″ exit 1.4″VC compression driver.

Recommended amplifer of 300 W at 8? will deliver 127dB SPL connections via 2 x Speakon NL4 In + Thru.

All housed in a 15mm Baltic birch ply cabinet with 35mm pole mount and a full length grille. optional brackets for installation are available.



£659.00

Description

PASSIVE REINFORCEMENT SPEAKER – 300w / 8 OHM 127dB SPL

For the VENTIS range, quality and flexibility are the watchwords. Based on a powerful combination of B&C compression drivers and FBT’s own custom, long excursion woofers, the 115, 112 and 110 models are two-way, bass reflex designs housed in 15mm birch plywood.

A full-grille design backed by specially treated acoustic cloth delivers the characteristic style for which FBT is known, while fully rotatable constant directivity horns ensure accurate coverage.

Features

  • Built-in passive crossover with soft-trip protection for the LF woofer and HF driver
  • Speakon NL-4 IN and LINK OUT connectors
  • 4 x M5 threaded rigging points and optional mounting hardware

Specifications

  • Configuration: 2 Wa
  • Frequency response: 60Hz – 18kHz -6dB
  • Low frequency woofer: 10″ / 2″ coil
  • High frequency driver: 1″ / 1.4″ coil
  • Crossover frequency: 1.8kHz
  • Input connector: 2x SpeakON NL4 (in & thru)
  • Net Dimension (WxHxD): 329 x 575 x 325mm
  • Net Weight: 15.1kg
  • Transport Dimension (WxHxD): 420 x 675 x 400mm
  • Transport Weight: 17.6kg
  • Recommended Amplifier: 300w RMS
  • Long term power: 130w
  • Short term power: 600w
  • Recommended HP filter: 50Hz – 12-24dB/Oct
  • Maximum SPL continuous/peak: 122/127dB
  • Nominal Impedance: 8 Ohm
  • Sensitivity (@1W/1m): 97dB
  • Dispersion (H x V): 80? x 50? rotatable
