Description

The Virtuoso 1000 Profile HEX (Body Only) features an advanced full colour LED system that outputs a flat and even field and is suitable for many applications. HSIC colour management allows you to create virtually any colour, whilst the virtual colour wheel provides direct access to many colours along with a 1,800K to 10,000K colour temperature control.

On board features include DMX, RDM and adjustable PWM rate. Due to the design of the body many common and aftermarket lens tubes can fit directly onto the fixture, allowing you to upgrade to LED without having to replace your existing lens tubes. Sold as the body only, with optional lenses and accessories.

Compatible with most industry-standard lenses, including Source 4.

Features

• 2-year warranty
• 1 x 270W six-colour LED Array (RGBALC)
• Beam angle: 5°- 50° dependent on lens used
• 30,105 Lux @ 2m (19° lens)
• 23,075 Lux @ 2m (26° lens)
• 14,005 Lux @ 2m (36° lens)
• 8,393 Lux @ 2m (50° lens)
• 46,519 Lux @ 2m (15-30° lens) (narrow)
• 16,127 Lux @ 2m (15-30° lens) (wide)
• 20,093 Lux @ 2m (25-50° lens) (narrow)
• 8,165 Lux @ 2m (25-50° lens) (wide)
• CRI Ra: 95
• CRI R9: 90
• CQS: 95
• TLCI: 80
• Colour temperature: 1,800K-10,000K
• Refresh rate: 5 selectable presets between 1.2kHz-25kHz
• Beam framing shutters
• Instant fast focus mode
• DMX channels: 3/7/8/10/13 or 20 selectable
• RDM (Remote Device Management)
• 0 – 100% 8 or 16 bit dimming
• Variable strobe
• 4 dimming curves: Linear, square law, inverse square law and S-curve
• 4 button menu with LCD display
• Power consumption: 311W
• Power supply: 100~240V, 50/60Hz
• Fuse: T6.3A 250V
• PowerTwist TR1 input/output
• 5-Pin XLR input/output
• 3 selectable fan modes (live, power and studio)
• Rear handle
• Quick release omega clamp included

Dimensions

• Dimensions (HxWxD): 588 x 390 x 522mm
• Weight: 8.5kg

Downloads

• ELUM143_Manual

Additional information
