Description

The Virtuoso 2000 Fresnel WW is a bright and compact lighting fixture featuring an advanced WW LED system, which excels in delivering super smooth dimming and is suitable for multiple applications.

On board features include DMX, RDM and adjustable PWM rate. The fixture is enclosed in a compact, robust chassis and features a motorised zoom with a 15° – 60° beam angle, providing designers with remote adjustment for additional flexibility.

Features

• 2-year warranty
• 1 x 220W warm white COB LED (3,200K)
• Adjustable beam angle: 15°- 60°
• 15° – 13,965 Lux @ 2m (full on), 60° – 2,218 Lux @ 2m (full on)
• CRI: 96.1
• Refresh rate: 600Hz, 1.2kHz, 2.4kHz, 4kHz, 6kHz or 25kHz selectable
• DMX channels: 1/2/3 or 5 selectable
• RDM (Remote Device Management)
• Can be used with a traditional dimmer pack
• Manual and master/slave modes
• 0 – 100% 8 or 16 bit dimming
• 4 dimming curves: Linear, square law, inverse square law and S-curve
• Variable strobe
• 4-button menu with LCD display
• Power consumption: 233W
• Power supply: 100/240V, 50/60Hz (voltage selector switch)
• Fuse: T3.15A 250V
• PowerTwist TR1 input/output
• 5-Pin XLR input/output
• 3-Pin XLR input/output
• 3 selectable fan modes (live, power and studio)
• Rear handle
• Filter frame included

Dimensions

• Dimensions (HxWxD): 389 x 285 x 383mm
• Weight: 6.2kg
• Packed Dims (HxWxD): 35.5 x 49.5 x 35cm
• Packed Weight: 8.3kg

Downloads

• ELUM142_Manual

Additional information
