MERZ Distribution Box 63A 3PH In/Thru to 32A/16A RCBO

MERZ Distribution Box 63A 3PH In/Thru to 32A/16A RCBO

The Elumen8 63A distribution boxes are manufactured using PCE components fitted into a MERZ enclosure, creating a robust, lightweight unit made of shock-resistant thermoplastic. Suitable for events and rental, they are IP44 splash proof rated.

£3,049.00

View your Basket

Description

The Elumen8 63A distribution boxes are manufactured using PCE components fitted into a MERZ enclosure, creating a robust, lightweight unit made of shock-resistant thermoplastic. Suitable for events and rental, they are IP44 splash proof rated.

Features

  • Made in Britain
  • Handy, robust distribution box made of shock-resistant thermoplastic
  • IP44 rated
  • Stackable design for space saving
  • All outlets feature a red indicator lamp
  • External earth stud

Specifications

  • Input: 63A 400V 3P+N+E IP67 appliance inlet
  • Pass Through: 63A 415V~50/60Hz 5-Pin 3P+N+E IP44 chassis socket
  • Outputs: 6 x 32A 230V 2P+E IP44 sockets each protected by 32A 30mA 2-Pole RCBO, 12 x 16A 230V 2P+E IP44 sockets each protected by 16A 30mA 2-Pole RCBO
  • Dimensions (H x W x D): 545 x 770 x 400mm
  • Weight: 23.1kg

Additional information

Weight 5 kg
